XB-ART-53094
Genes Dev
2017 Feb 01;313:275-290. doi: 10.1101/gad.291799.116.
Show Gene links
Show Anatomy links
CRL2Lrr1 promotes unloading of the vertebrate replisome from chromatin during replication termination.
???displayArticle.abstract???
A key event during eukaryotic replication termination is the removal of the CMG helicase from chromatin. CMG unloading involves ubiquitylation of its Mcm7 subunit and the action of the p97 ATPase. Using a proteomic screen in Xenopus egg extracts, we identified factors that are enriched on chromatin when CMG unloading is blocked. This approach identified the E3 ubiquitin ligase CRL2Lrr1, a specific p97 complex, other potential regulators of termination, and many replisome components. We show that Mcm7 ubiquitylation and CRL2Lrr1 binding to chromatin are temporally linked and occur only during replication termination. In the absence of CRL2Lrr1, Mcm7 is not ubiquitylated, CMG unloading is inhibited, and a large subcomplex of the vertebrate replisome that includes DNA Pol ε is retained on DNA. Our data identify CRL2Lrr1 as a master regulator of replisome disassembly during vertebrate DNA replication termination.
???displayArticle.pubmedLink??? 28235849
???displayArticle.pmcLink??? PMC5358724
???displayArticle.link??? Genes Dev
???displayArticle.grants??? [+]
Species referenced: Xenopus laevis
Genes referenced: eif4g2 mcm7
