XB-ART-14930Development 1998 Jul 01;12513:2425-32. doi: 10.1242/dev.125.13.2425.
Show Gene links Show Anatomy links
Genetic circuits responsible for the development of photoreceptive organs appear to be evolutionarily conserved. Here, the Xenopus homologue Xtll of the Drosophila gene tailless (tll), which we find to be expressed during early eye development, is characterized with respect to its relationship to vertebrate regulators of eye morphogenesis, such as Pax6 and Rx. Expression of all three genes is first detected in the area corresponding to the eye anlagen within the open neural plate in partially overlapping, but not identical, patterns. During the evagination of the optic vesicle, Xtll expression is most prominent in the optic stalk, as well as in the distal tip of the forming vesicle. In tadpole-stage embryos, Xtll gene transcription is most prominent in the ciliary margin of the optic cup. Inhibition of Xtll function in Xenopus embryos interferes specifically with the evagination of the eye vesicle and, in consequence, Xpax6 gene expression is severely reduced in such manipulated embryos. These findings suggest that Xtll serves an important regulatory function in the earliest phases of vertebrate eye development.
PubMed ID: 9609825
Article link: Development
Species referenced: Xenopus
Genes referenced: en2 nr2e1 pax6 rax sox3 tbx2 tll1
Article Images: [+] show captions
|Fig. 1. Xtll and Xpax6 mRNA levels during Xenopus embryogenesis and in adult tissues. Quantitative reverse transcriptase-PCR analysis was performed with total RNA preparations from staged embryos (as indicated by numbers) and from adult tissues. Tissues were: B, brain; SC, spinal cord; EY, eye; N, nerves; H, heart; M, skeletal muscle; S, skin; LI, liver; K, kidney; L, lung; I, intestine; ST, stomach; SP, spleen; O, ovary; T, testis. The two different PCR products obtained with primers specific for Xpax6 reflect differential splicing within the region encoding the Paired box (data not shown), as also found in other vertebrates (Epstein et al., 1994). Transcription of both genes is activated during neurulation; Xpax6 starts to be expressed earlier than Xtll.|
|Fig. 2. Comparative analysis of the spatial expression patterns of genes expressed in the context of early eye development in Xenopus. Whole-mount in situ hybridization experiments were performed with staged embryos (as indicated by numbers). Hybridization reactions were either specific for Xtll (E-H) and Xpax6 (M-P), respectively, or a combination of Xtll (purple) and Sox3 (red) (D), or a combination of Xtll (purple) with engrailed (red) (I), or with Xrx (red) (A-C), or with Xpax6 (red) (J-L). All embryos are shown in a dorso-anterior view. En-2 demarcates the midbrain-hindbrain boundary (Hemmati-Brivanlou et al., 1991), Sox3 is expressed in the entire neural plate as well as in the lens anlage (R. Grainger, personal communication). Horizontal sections were prepared at the level of the eye from stage- 17 and stage-23 embryos which had been stained for Xtll and Xpax6 expression (Q-T). Xtll and Xpax6 are expressed in the early eye as well as in the developing central nervous system. ar, archenteron; ev, eye vesicle; fb, forebrain; os, optic stalk.|
|Fig. 3. Comparative analysis of Xtll and Xpax6 expression in Xenopus tadpoles. Stage-34 Xenopus tadpoles or isolated brain, eye and spinal cord from the same stage were stained for either Xtll (A,B) or Xpax6 mRNA (D,E). Xtll expression (purple) was also compared with en2 (red, C) and Xpax6 (red, F). Both genes are transcribed in forebrain, midbrain and in the eye. Transverse sections from stage-36 embryos at the level of the eye define differentially regulated Xtll (G, purple in H) and Xpax6 (I, red in H) expression domains. In the eye, Xtll expression is specific to the distal tips of the eye cup, whereas Xpax6 is strongly expressed in the neural retina as well as in the lens. Sections corresponding to a more anterior position reveal expression of both genes in the olfactory placodes (data not shown). cm, cilary margin; dt, dorsal thalamus; ey, eye; gu, gut; hy, hypothalamus; lp, lens epithelium; le, lens; mb, midbrain; mhb, midbrain hindbrain boundary; nr, neural retina; np, nasal placode; ov, otic vesicle.|
|Fig. 4. Inhibition of Xtll function in Xenopus embryos specifically interferes with the eye development. Xenopus embryos were injected with a mRNA encoding the Xtll-ZF-engR construct and allowed to develop to stage 34 (A,B) or stage 50 (C,D). The injected side of these embryos is shown in B and D. The fact that disturbed eye development was indeed exclusive to the injected side of the embryo was established by coinjection of mRNA encoding b-galactosidase and staining of tadpole-stage embryos for enzymatic activity (data not shown). A schematic representation of the Xtll-ZF-engR construct in relation to the wild-type version of Xtll is shown in E.|
|Fig. 5. Inhibition of Xtll function specifically interferes with the evagination of the eye vesicle during early embryogenesis. Transverse sections from stage-34 Xenopus embryos that had been injected with a mRNA encoding the Xtll-ZF-engR construct and which were stained for Xpax6 expression reveal the complete absence (B) or severe reduction (A) of the eye structure in the injected half of the embryo. Ectopic Xpax6 expression is denoted by an arrow in B. Analysis of Xpax6 expression in microinjected embryos grown to either stage 19 (C) or stage 23 (E), as well as of horizontal sections at the level of the eye prepared from the same embryos (D and F, respectively) reveals that counteracting Xtll function in the embryo results in the inhibition of eye vesicle evagination. The lines in C and E indicate the approximate plane of section. ev, eye evagination; eym, endodermal yolk mass; fg, forgut; nc, notochord; pev; prosencephalic ventricle.|
